11
03.96
11.2 Data backup via MMC 100
11-251
Siemens AG 2000 All Rights Reserved
SINUMERIK 840D Installation and Start-Up Guide (IAD) – 04.00 Edition
8. Select softkey “Data selection” and the areas to be read out. The area “NC
active data”, for example, contains the following data:
– Machine data
– Setting data
– Option data
– Global and local user data
– Tool and magazine data
– Protection zones
– R parameters
– Zero offsets
– Drive data
– Compensation data
– Display machine data
– Workpieces, global part programs/subroutines
– Standard and user cycles
– Definitions and macros
When the areas are output, the internal area identifier used in each case
appears on the top line of the display.
9. Start reading out (softkey Start) and acknowledge any prompts on the oper-
ator panel.
Note
The SIMATIC HiGraph tools can be used to save PLC area data.
Note filter setting for SDBs!
References: /S7HT/ Manual, Application of Tools
These tools are useful in ensuring portability of the PLC programs.
To read in an entire configuration first perform a general reset of the control.
1. Set the protection level:
– up to SW 3.x to “Manufacturer” (password SUNRISE)
– in SW 4 and higher to “User” (password CUSTOMER)
2. Connect the PG/PC to interface X6 on the MMC.
3. Select the “Services” operating area on the MMC. Continue with steps listed
under “Reading in series start-up” or “Reading in area-specific archive data”.
Loading archiving
data
11 Data Backup
08.97
