11.8 Line checksums and MD numbers in MD files (software version 3.2 and higher)
11-283
Siemens AG 2000 All Rights Reserved
SINUMERIK 840D Installation and Start-Up Guide (IAD) – 04.00 Edition
MD 11220 value
Reaction to errors
0 Output of an alarm, abort on detection of 1st error (as for
SW version 1 and 2).
1 Output of an alarm, continuation of file import, alarm out-
puts number of errors at file end.
2 Import process continues to end of file even if errors are
detected. Alarm outputs number of errors at file end.
In all cases where at least one error is detected in the MD file, the name of the
affected file is output by means of alarm 15180.
Other reactions:
S MD containing errors do not overwrite current MD.
S The current MD are not overwritten when an attempt is made to load MD
with no line checksums without adequate write authorization.
S CHANDATA instructions for nonexistent channels (MD for multiple channel
configuration are not set) cause import process to be aborted.
S Invalid file end causes import process to be aborted.
Das MD 11220 INI_FILE_MODE must be reset explicitly. An earlier setting is not
accepted in the course of series start
-up.
S Import machine data and output alarms generated on import.
S % character stands for file name and number of errors.
S MD 11220 = 1, i.e. output of an alarm for every error, continuation of proc-
essing, alarm outputs of errors at end of file.
MD file Alarms
CHANDATA(1)
$MC_AXCONF_GEOX_NAME_TAB[0]=“X”
$MC_AXCONF_GEOX_NAME_TAB[1]=“Y”
15180 Program % cannot be processed as INI file
$MC_AXCONF_GEOX_NAME_TAB[99]=“A” 17020 Illegal array index 1
$MC_MM_REORG_LOG_FILE_MEM=1000 17090 Value greater than upper limit
$MC_AXCONF_GEOX_NAME_TAB=“X” 12400 Element does not exist
$MC_MM_REORG_LOG_FILE_MEM[1]=100 12400 Element does not exist
$MN_UNKNOWN_MD=1 12550 Name % not defined
M17
15185 % Error detected in INI file
MD 11220
INI_FILE_MODE
Example:
