12
03.96
12.4 Upgrading the NC
12-294
Siemens AG 2000 All Rights Reserved
SINUMERIK 840D Installation and Start-Up Guide (IAD) – 04.00 Edition
1. Start “sinucopy-ffs.exe” file
2. Enter password
3. Dialog: Specify a temporary directory for extracting the files
4. Dialog: Specify the hardware configuration
5. Dialog: Select the components to be installed
6. Dialog: Specify the directory for the installation
7. The software is installed
8. Message: “driver installed”
9. Dialog: “Select program folder name”
10. Dialog: Please read the READ ME file
11. Dialog: Restart now or later
12. After a restart, the SINUCOPY–FFS function can be used
This tool is intended for experts.
S Read archive files
S Delete/insert files
S Modify files (if editable)
This tool is intended for experts.
S Read and write data to NC cards
S Duplicate NC cards
Note
1. Programming device with SINUCOPY (previous version)
The installation may be unsuccessful if the driver “cisio-s” is entered in the
“config.sys” file and it is detected during power-up: Error message. Rem-
edy:
– Delete the line “Device ...cisio.exe, cisio.ini”.
– In the “cisio.ini” file, enter a free interrupt number as a hex number in the
line IRQ=....
You can determine a free interrupt number from the menu “Properties
for system”– “Device manager”.
2. If an NC card with FFS is duplicated with the previous version SINUCOPY,
only the NC system (not the FFS part) is duplicated.
3. The drive name for the OMNI97 device can be entered: Enter the drive let-
ter in the menu “System control/Device manager/Drives/OMNI97”.
Windows NT: Enter the drive letter in the menu “OmniControl/DriveLetter”.
Installation
Tool: ARCEDIT
Tool: SICARD
12 Software and Hardware Replacement
12.98
