3.5 Handheld programming unit
3-62
 Siemens AG 2000 All Rights Reserved
SINUMERIK 840D Installation and Start-Up Guide (IAD) – 04.00 Edition
table 1
GD identifiers as314/CPU1:: MCP/CPU1:: HPU/CPU1::
GD
»qb0:8
qb0:8
GD ib0:8
»ib0:8
GD
»qb16:8
qb16:8
GD ib16:8
»ib16:8
Note
The order in which inputs are made (transmit, receive) affects the way in which
GD identifiers are assigned and should be noted carefully as shown by the
above example.
Now select compiling.
The GD identifiers are generated during compilation. The GD identifiers are dis-
played as the result in table 1:
table 1
GD identifiers as314/CPU1:: MCP/CPU1:: HPU/CPU1::
GD 1.1.1
»qb0:8
qb0:8
GD 1.2.1 ib0:8
»ib0:8
GD 2.1.1
»qb16:8
qb16:8
GD 2.2.1 ib16:8
»ib16:8
Compiling
