Detailed description
2.3 Starting up hardware configuration of PLC CPUs
Basic logic functions: PLC Basic program powerline (P3 pl)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
17
2.3 Starting up hardware configuration of PLC CPUs
General procedure
STEP 7 is used to define the hardware configuration for a PLC CPU, including the
associated I/O.
The procedure to be followed is shown below:
1. Load tool box to PG/PC
2. Create a new project (File, New, Project)
3. Insert, Hardware, SIMATIC 300 station
4. Select SIMATIC 300 station1 with mouse
5. Open object by right-clicking with the mouse to start the HWConfig
6. Destination system, load to PG, the hardware equipment complement is read back from
the central system
7. Configure distributed I/Os
8. Insert PLC basic program
The addresses for the I/O modules can be changed if necessary (permissible only on certain
PLC CPUs, e.g. PLC 3152DP).
As an alternative, the entire hardware configuration can be entered manually (see also
appropriate STEP7 documentation). The notices below must be observed.
STEP7, Version 3
With STEP7 Version 3 and higher, the hardware configuration of the SINUMERIK
components must be defined via the entries in SIMATIC\RACK 300. The install or setup
program of the basic program on the tool box diskettes is required for this purpose.
STEP7 Version 5.1 SP2 and Toolbox 6.03.02
With STEP7 V5.1 SP2 and Toolbox 6.03.02 or later, the SINUMERIK components are stored
under SIMATIC 300\SINUMERIK. The current hardware expansion for STEP 7 can also be
found under eSupport.
Current path (02/13/2004): sinumerik_software > 840d/810d/fm-nc > patches & fixes > plc >
Hardware_fuer_STEP7 > Hardware upto NCU*.5/CCU3/840Di_MCI2 > V6.5.2.0
NCU
MLFB
Comparable
SIMATIC CPU MLFB
included
Selection from STEP7 hardware
catalog
CCU1 810D CPU 6FC5 410-0AA00-0AA0 6ES7 314-1AE01-0AB0 810D/840D with PLC314
CCU2 810D CPU 6FC5 410-0AA01-0AA0 6ES7 314-1AE01-0AB0 810D/840D with PLC314
CCU1 810DE CPU 6FC5 410-0AY01-0AA0 6ES7 314-1AE01-0AB0 810D/840D with PLC314
CCU2 810D CPU 6FC5 410-0AX02-0AA0 6ES7 314-1AE01-0AB0 810D/840D with PLC314
SINUMERIK 810DE Light
CCU1 module
with system software (export)
6FC5 410-0AY00-0AA0 6ES7 314-1AE01-0AB0 810D/840D with PLC314
