Detailed description
2.11 Supplementary conditions and NC VAR selector
Basic logic functions: PLC Basic program powerline (P3 pl)
84 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Block size (bytes)
Block
type no.
Function
Remark
Load
memory
Working
memory
Maximum configuration (2 channels, 4 spindles, 4 axes, TMCP)
See above Basic program, base 14796 11720
See above Interface DBs 2542 2090
See above MCP 2300 1962
See above Error/operating messages 1572 1350
See above ASUBs 1 ASUB initiation 656 538
See above Concurrent axis For 2 turrets 674 560
See above PLC/NC communication 1 x read variable and 1 x write variable 8070 6388
See above Tool management 2 turrets with one loading point each 3430 2854
See above Compile cycles 472 436
Total 34512 27898
2.11 Supplementary conditions and NC VAR selector
2.11.1 Supplementary conditions
2.11.1.1 Programming and parameterizing tools
Basics
Hardware
Programming devices or PCs with the following equipment are required for the PLCs
installed on the 810D and 840D:
Minimum Recommendation
Processor 80486 Pentium
RAM (MB) 32 Or more
Hard disk,
free capacity (MB)
200 > 400
Interfaces MPI incl. cable
Memory card
Graphics VGA or TIGA SVGA
Mouse yes
