Detailed Description
2.8 Special handling of tool compensations
Basic logic functions: Tool Offset (W1)
132 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Supplementary conditions
If the "Scratch" function is used in the RESET state, the following must be noted with respect
to the initial setting:
The wear components are evaluated depending on the initial settings of the G-code
groups TOWSTD, TOWMCS and TOWWCS.
If a value other than the initial setting is needed to ensure correct calculation, scratching
may be performed only in the STOP state.
Note
"Special handling of tool compensations" pays particular attention to tool compensations
with evaluation of sign for tool length with wear and temperature fluctuations.
The following are taken into account:
Tool type
Transformations for tool components
Assignment of tool length components to geometry axes independently of tool type
2.8 Special handling of tool compensations
2.8.1 Relevant setting data
SD42900- 42960
Setting data SD42900 - SD42940 can be used to make the following settings with reference
to tool compensation:
Sign of the tool length
Sign of the wear
Behavior of the wear components when mirroring geometry axes
Behavior of the wear components when changing the machining plane via setting data
Allocation of the tool length components independent of actual tool type
Transformation of wear components into a suitable coordinate system for controlling the
effective tool length
