Detailed description
2.2 Userdefined auxiliary functions
Basic logic functions: Auxiliary Function Output to PLC (H2)
30 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
2.2.5 Parameterization
2.2.5.1 Parameter: Group assignment
Group assignment
Group assignment is used to assign a user-defined auxiliary function to an auxiliary function
group using the machine data:
MD22000 $MC_AUXFU_ASSIGN_GROUP[ index ] (group assignment)
If the value is zero, the auxiliary function is not assigned to any auxiliary function group.
For the meanings of the auxiliary function groups, see section: Auxiliary function groups.
2.2.5.2 Parameter: Type, address extension, and value
Function
A user-defined auxiliary function is programmed via the parameters:
• Type
MD22010 $MC_AUXFU_ASSIGN_TYPE[ Index ] (type of auxiliary function)
• Address extension
MD22020 $MC_AUXFU_ASSIGN_EXTENSION[ Index ] (auxiliary function extension)
• Value
MD22030 $MC_AUXFU_ASSIGN_VALUE[ Index ] (auxiliary function value)
Syntax:
< type > [ < address extension > = ] < value >
Parameter: Type
The name of an auxiliary function is defined via the "type".
The identifiers for user-defined auxiliary functions are:
Type Identifier Meaning
H Auxiliary function User-specific auxiliary functions
M Additional function
S Spindle function
T Tool number
Extension of predefined auxiliary
functions
