2.11 General conditions and NC-VAR_Selector
Basic logic functions: PLC basic program solution line (P3 sl)
82 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
2.11 General conditions and NC-VAR_Selector
2.11.1 Supplementary conditions
2.11.1.1 Programming and parameterizing tools
Hardware
Programming devices or PCs with the following equipment are required for the PLCs
installed on the SINUMERIK 810D and 840D:
Minimum Recommendation
Processor Pentium Pentium
RAM (MB) 256 512 or more
Hard disk,
free capacity (MB)
500 > 500
interfaces MPI, Ethernet incl. cable
Memory card
Graphic SVGA (1024*768)
Mouse Yes
Operating system Windows 2000 /XP Professional, STEP7 version 5.3 SP2 or
higher
The required version of STEP7 can be installed on equipment meeting the above
requirements in cases where the package has not already been supplied with the
programming device.
The following functions are possible with this package:
• Programming
– Editors and compilers for STL (complete scope of the language incl. SFB/SFC calls),
LAD, FBD
– Creation and editing of assignment lists (symbol editor)
– Data block editor
– Input and output of blocks ON/OFF line
– Insertion of modifications and additions ON and OFF line
– Transfer of blocks from programming device to the PLC and vice versa
• Configuring
– Parameterizing tool HW Config for CPU and I/O device parameterization
– NetPro parameterizing tool for setting the CPU communication parameters
– Output of system data such as hardware and software version, memory capacity, I/O
expansion/assignment
