Basic logic functions: Various NC/PLC interface signals and functions (A2)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
47
Data lists
5
5.1 Machine data
5.1.1 Drive-specific machine data
Number Identifier: $MD_ Description
1403 PULSE_SUPPRESSION_SPEED Shutoff speed for pulse suppression
1404 PULSE_SUPPRESSION_DELAY Time for pulse suppression
1417 SPEED_THRESHOLD_X n
x
for n
act
< n
setp
signal
1418 SPEED_THRESHOLD_MIN n
min
for n
act
< n
setp
signal
1426 SPEED_DES_EQ_ACT_TOL Tolerance band for n
set
= n
act
signal
1427 SPEED_DES_EQ_ACT_DELAY Delay time n
set
= n
act
signal
1428 TORQUE_THRESHOLD_X Threshold torque
1429 TORQUE_THRESHOLD_X_DELAY Delay time n
d
< n
dx
signal
1602 MOTOR_TEMP_WARN_LIMIT Maximum motor temperature
1603 MOTOR_TEMP_ALARM_TIME Time for motor temperature alarm
1604 LINK_VOLTAGE_WARN_LIMIT DC link under voltage warning threshold
5.1.2 Memory specific machine data
Number Identifier: $MM_ Description
HMI
Advanced
HMI
Embedded
9000 9000 LCD_CONTRAST Contrast
9001 9001 DISPLAY_TYPE Monitor type
9002 DISPLAY_MODE external monitor (1: black and white, 2: color)
9003 FIRST_LANGUAGE Foreground language
9004 9004 DISPLAY_RESOLUTION Display resolution
9005 PRG_DEFAULT_DIR Basic setting Program directory
9006 DISPLAY_BLACK_TIME Time setting for screen saver
