Data lists
5.2 Setting data
Basic logic functions: Spindles (S1)
100 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
5.2 Setting data
5.2.1 Channelspecific setting data
Number Identifier: $SC_ Description
42600 JOG_FEED_PER_REF_SOURCE Revolutional feedrate control in JOG mode
42800 SPIND_ASSIGN_TAB Spindle number converter
42900 MIRROR_TOOL_LENGTH Mirror tool length offset
42910 MIRROR_TOOL_WEAR Mirror wear values of tool length compensation
42920 WEAR_SIGN_CUTPOS Mirror wear values of machining plane
42930 WEAR_SIGN Invert sign of all wear values
42940 TOOL_LENGTH_CONST Retain the assignment of tool length components
when changing the machining plane (G17 to G19)
5.2.2 Axis/spindle-specific setting data
Number Identifier: $SA_ Description
43200 SPIND_S Specification of the spindle speed
43202 SPIND_CONSTCUT_S Specification of the constant cutting rate for the
master spindle
43210 SPIND_MIN_VELO_G25 Progr. Spindle speed limitation G25
43220 SPIND_MAX_VELO_G26 Progr. Spindle speed limitation G26
43230 SPIND_MAX_VELO_LIMS Progr. spindle speed limitation G96/G961
43240 M19_SPOS Spindle position for spindle positioning
with M19
43250 M19_SPOSMODE Spindle positioning approach mode for
spindle positioning with M19
43300 ASSIGN_FEED_PER_REF_SOURCE Rotational feedrate for positioning axes/spindles
