Detailed description

2.10 System settings for power-up, RESET/part-program end and part-program start

Basic logic functions: Mode group, channel, program operation, reset response (K1)

164 Function Manual, 11/2006, 6FC5397-0BP10-2BA0

2.10 System settings for power-up, RESET/part-program end and part-

program start

Concept

The control system response can be altered for functions such as G codes, tool length

compensation, transformation, coupled axis groupings, tangential followup, and

programmable synchronous spindle after

• Power up (power ON),

• Reset/part program end and

• Part program start

The

MD20110 $MC_RESET_MODE_MASK (defining the initial controller setting after Reset / part

program start)

MD20150 $MC_GCODE_RESET_VALUES (RESET position of G groups) and its extension

MD20152 $MC_GCODE_RESET_MODE (defining the initial controller setting

during Reset) and

MD20112 $MC_START_MODE_MASK (defining initial controller setting

after part program start)

For certain applications (e.g., grinding) it is advisable not to capture the reset position of

individual functions until part program start. This is possible through the appropriate setting

of MD20110, MD20150, MD20152 and MD20112.

Table 2-12 Change system settings by means of MD

Status Can be changed in MD

Power up (POWER ON) MD20110 $MC_RESET_MODE_MASK

MD20150 $MC_GCODE_RESET_VALUES

RESET/part program end MD20110 $MC_RESET_MODE_MASK

MD20150 $MC_GCODE_RESET_VALUES

MD20152 $MC_GCODE_RESET_MODE

Part program start MD20110 $MC_START_MODE_MASK and

MD20112 $MC_RESET_MODE_MASK
