Detailed Description
2.10 Axis types, coordinate systems, frames (K2)
Basic logic functions: NC/PLC interface signals (Z1)
108 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
2.10 Axis types, coordinate systems, frames (K2)
2.10.1 Signals to axis/spindle (DB31, ...)
DB 31, ...
DBX3.0
External Zero Offset
Edge evaluation: no Signal(s) updated:
Signal state 1 or
edge change
0 → 1
The preselected value of the external work offest of an axis is used as the new value for calculating
the total work offset between the basic and the workpiece coordinate systems.
Signal state 0 or
edge change
1 → 0
The preselected value of the external work offset of an axis is not used as the new value for
calculating the total work offset between the basic and workpiece coordinate systems. The previous
value is still valid.
Signal irrelevant for
...
$AA_ETRANS[axis] equals zero for all axes.
Special cases,
errors, ......
Signal zero after ramp-up (power ON).
Corresponding to .... $AA_ETRANS[axis]
2.11 EMERGENCY STOP (N2)
2.11.1 Signals to NC (DB10)
DB10
DBX56.1
EMERGENCY STOP
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
The NC is switched to the EMERGENCY STOP state and the EMERGENCY STOP procedure is
started on the NC.
Signal state 0 or
edge change
1 → 0
The NC is not in the EMERGENCY STOP state.
The EMERGENCY STOP status is (still) active but can be reset using the interface signals:
DB10 DBX56.2 (acknowledge EMERGENCY STOP)
and
DB11 DBX0.7 (mode group reset)
Corresponding to .... DB10 DBX56.2 (acknowledge EMERGENCY STOP)
DB10 DBX106.1 (acknowledge EMERGENCY STOP)
