5.3 Signals
Basic logic functions: Axis monitoring, protection zones (A3)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
83
DB number Byte.Bit Description
21, ... 273.1 Machinerelated protection zone 10 preactivated
21, ... 274.0 Channelspecific protection zone 1 preactivated
: :
21, ... 274.7 Channelspecific protection zone 8 preactivated
21, ... 275.0 Channelspecific protection zone 9 preactivated
21, ... 275.1 Channelspecific protection zone 10 preactivated
21, ... 276.0 Machinerelated protection zone 1 violated
: :
21, ... 276.7 Machinerelated protection zone 8 violated
21, ... 277.0 Machinerelated protection zone 9 violated
21, ... 277.1 Machinerelated protection zone 10 violated
21, ... 278.0 Channelspecific protection zone 1 violated
: :
21, ... 278.7 Channelspecific protection zone 8 violated
21, ... 279.0 Channelspecific protection zone 9 violated
21, ... 279.1 Channelspecific protection zone 10 violated
5.3.3 Signals to axis/spindle
Axis monitoring functions
DB number Byte.Bit Description
31, ... 1.4 Follow up operation
31, ... 1.5 / 1.6 Position measuring system 1 / 2
31, ... 2.1 Servo enable
31, ... 2.3 Clamping in progress
31, ... 3.6 Velocity/spindle speed limitation
31, ... 4.3 Feed stop
31, ... 12.0 / 12.1 Hardware limit switch minus/Hardware limit switch plus
31, ... 12.2 / 12.3 Software limit switch minus / 2nd software limit switch plus
31, ... 60.2 / 60.3 Encoder limit frequency exceeded 1 / 2
31, ... 60.4 / 60.5 Referenced/synchronized 1 / 2
31, ... 64.6 / 64.7 Traverse command minus / plus
Protection zones
None
