2.3 Coordinate systems

Basic logic functions: Axes, coordinate systems, frames (K2)

40 Function Manual, 11/2006, 6FC5397-0BP10-2BA0

2.3.2 Machine coordinate system (MCS)

Machine coordinate system (MCS)

The machine coordinate system (MCS) is made up of all physically available machine axes.

;

&

<

=



Figure 2-13 MCS with machine axes X, Y, Z, B, C (5axis milling machine)

Function Manual - Basic Functions1
