Basic logic functions: Continuouspath Mode, Exact Stop, LookAhead (B1)

Function Manual, 11/2006, 6FC5397-0BP10-2BA0

Examples

4.1 Example of jerk limitation on the path

...

N1000 G64 SOFT

; Continuous-path mode with SOFT acceleration

characteristics

N1004 G0 X-20 Y10

N1005 G1 X-20 Y0

; Straight

N1010 G3 X-10 Y-10 I10

; Block transition with jump in path curvature

(straight - circular)

N1011 G3 X0 Y0 J10

; Block transition with continuous path curvature

N1020 G2 X5 Y5 I5

; Block transition with jump in path curvature

(circular - circular)

N1021 G2 X10 Y0 J-5

...

Function Manual - Basic Functions1
