Siemens SINUMERIK 810D Function Manual

Detailed description
2.3 Starting up hardware configuration of PLC CPUs
Basic logic functions: PLC Basic program powerline (P3 pl)
20 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
NCU MLFB
Comparable
SIMATIC CPU MLFB
included
Selection from STEP7 hardware
catalog
SINUMERIK 840D NCU
573.2 (Pentium Pro) (export
version) for 12 axes with
PROFIBUS DP
6FC5 357-0BY32-1AE0 6ES7 315-2AF01-0AB0 810D/840D with PLC3152AF01
SINUMERIK 840D NCU
573.2 (Pentium Pro) (export
version) for 31 axes with
PROFIBUS DP
6FC5 357-0BY33-1AE0 6ES7 315-2AF01-0AB0 810D/840D with PLC3152AF01
SINUMERIK 840D NCU
573.2 (Pentium Pro) (export
version) for digitizing with
PROFIBUS DP
6FC5 357-0BY31-1AE0 6ES7 315-2AF01-0AB0 810D/840D with PLC3152AF01
SINUMERIK 840Di 6FC5 220-0AA00-1AA0 6ES7 315-2AF03-0AB0 810D/810Di with PLC315-2AF03
SINUMERIK 840Di with PK
bus
6ES7 315-2AF03-0AB0 810D/810Di with PLC315-2AF03,
PK bus
SINUMERIK 840D NCU
572.3
6FC5 357-0BB22-0AE0 with operating system
03.10.23:
6ES7 315-2AF01-0AB0
810D/840D with PLC3152AF01
SINUMERIK 840D NCU
572.3
6FC5 357-0BB22-0AE0 with operating system
12.30.07:
6ES7 315-2AF03-0AB0
810D/840D with PLC315-2AF03
SINUMERIK 840D NCU
573.3
6FC5 357-0BB33-0AE2 6ES7 315-2AF01-0AB0 810D/840D with PLC3152AF01
SINUMERIK 840D NCU
573.3
6FC5 357-0BB33-0AE2 with operating system
12.30.07:
6ES7 315-2AF03-0AB0
810D/840D with PLC315-2AF03
(as of STEP7 V5.0 and Toolbox
05.03.05)
SINUMERIK 840D NCU
572.4
6FC5 357-0BB23-0AE0 6ES7 314-6CF00-0AB0 810D/840D with PLC314C-2DP
SINUMERIK 840D NCU
573.4
6FC5 357-0BB34-0AE1 6ES7 314-6CF00-0AB0 810D/840D with PLC314C-2DP
SINUMERIK 810D CCU3 6FC5 410-0AY03-0AA0 6ES7 315-2AF03-0AB0 810D/840D with PLC315-2AF03
SINUMERIK 840D NCU
571.3
6FC5 357-0BB11-0AE1 6ES7 315-2AF03-0AB0 810D/840D with PLC315-2AF03
SINUMERIK 840D NCU
561.3
6FC5356-0BB11-0AE1 6ES7 315-2AF03-0AB0 810D/840D with PLC315-2AF03
(as of STEP7 V5.0 and Toolbox
05.03.05)
SINUMERIK 840D NCU
571.4
6FC5357-0BB12-0AE0 6ES7 314-6CF00-0AB0 810D/840D with PLC314C-2 DP
(STEP7 V5.1 SP3 and higher
and Toolbox 06.03.02)
SINUMERIK 840D NCU
561.4
6FC5356-0BB12-0AE0 6ES7 314-6CF00-0AB0 810D/840D with PLC314C-2 DP
(STEP7 V5.1 SP3 and higher
and Toolbox 06.03.02)
SINUMERIK 840D NCU
573.5
6FC5357-0BB35-0A E0 6ES7 317-2AJ00-0AB0 810D/840D with PLC317-2 DP
(STEP7 V5.2 SP1 and higher
and Toolbox 06.05.02)
SINUMERIK 840Di with
MCI2
6FC5 222-0AA02-1AA0 6ES7 317-2AJ00-0AB0 810Di with PLC317-2 DP
(STEP7 V5.2 SP1 and higher
and Toolbox 06.05.02)
