Detailed description

2.12 Block descriptions

Basic logic functions: PLC Basic program powerline (P3 pl)

102 Function Manual, 11/2006, 6FC5397-0BP10-2BA0

Code Comment

BHGSendGDNo: INT:= 2;

BHGSendGBZNo: INT:= 1;

BHGSendObjNo: INT:= 1;

BHGMPI: BOOL:= FALSE;

BHGStop: BOOL:= FALSE;

BHGNotSend: BOOL:= FALSE;

NCCyclTimeout: S5TIME:= S5T#200MS;

NCRunupTimeout: S5TIME:= S5T#50S;

ListMDecGrp: INT:= 0;

NCKomm: BOOL:= FALSE;

MMCToIF: BOOL:= TRUE;

HWheelMMC: BOOL:= TRUE; //Handwheel selection via HMI

MsgUser: INT:= 10; //Number of user areas in DB 2

UserIR: BOOL:= FALSE; //User programs in OB 40,

//Observe local data expansion!

IRAuxfuT: BOOL:= FALSE; //Evaluate T function in OB 40

IRAuxfuH: BOOL:= FALSE; //Evaluate H function in OB 40

IRAuxfuE: BOOL:= FALSE; //Evaluate DL function in OB 40

UserVersion: POINTER; //Pointer to string variable indicated in

//version display

END_VAR

VAR_OUTPUT

MaxBAG: INT ;

MaxChan: INT ;

MaxAxis: INT ;

ActivChan: ARRAY[1..10] OF BOOL;

ActivAxis: ARRAY[1..31] OF BOOL;

UDInt : INT ;

UDHex: INT ;

UDRea l : INT ;

END_VAR
