Basic logic functions: PLC Basic program powerline (P3 pl)
138 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Parameter:
WVar1 = FunctionNumber
This function number represents a PI service:
1:
TMCRTO (create tool)
2:
TMFDPL (search for empty location for loading):
3:
TMMVTL (prepare magazine location for loading, unload tool)
4:
TMFPBP (search for location)
5:
TMGETT (search for tool number)
6:
TSEARC (search for tool)
7 ...
10:
Reserved
WVar2=SemaphorValue
0:
Reset semaphore
1:
Test and set semaphore
Parameterization
Signal Type Value range Meaning
PIService ANY PI.MMCSEM Set semaphore
Unit INT 1, 2 to 10 Channel
WVar1 INT 1 to 10 FunctionNumber
WVar2 WORD 0, 1 SemaphoreValue
