Detailed description
2.12 Block descriptions
Basic logic functions: PLC Basic program powerline (P3 pl)
172 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Description of formal parameters
The following table lists all of the formal parameters of the brake test function
Formal parameters of brake test function
Signal I/O Type Remark
Start I BOOL Start brake test
Ack I BOOL Acknowledge error
Bclosed I BOOL Checkback input whether Close Brake is activated
(singlechannel - PLC)
Axis I INT Axis number of axis to be tested
TimerNo I TIMER Timer from user program
TV_BTactiv I S5TIME Monitoring time value -> brake test active, check of axis
signal DBX71.0
TV_Bclose I S5TIME Monitoring time value -> close brake Check of input
signal Bclosed after output CloseBrake has been set.
TV_FeedCommand I S5TIME Monitoring time value -> issue travel command Check
travel command after MoveAxis has been set.
TV_FXSreched I S5TIME Monitoring time value -> fixed stop reached
TV_FXShold I S5TIME Monitoring time value -> test brake
CloseBrake Q BOOL Request, close brake
MoveAxis Q BOOL Request, initiate traversing motion
Done Q BOOL Test successfully completed
Error Q BOOL Error occurred.
State Q BYTE Error status
