Detailed description
2.12 Block descriptions
Basic logic functions: PLC Basic program powerline (P3 pl)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
233
MCP selection signals to the user interface
Key switch
Source:
MCP-Switch
Destination:
Interface DB
Position 0 DB10.DBX56.4
Position 1 DB10.DBX56.5
Position 2 DB10.DBX56.6
Position 3 DB10.DBX56.7
Operating modes and machine functions
Source:
MCP key
Destination:
Interface DB (parameter ModeGroupNo)
AUTOMATIC DB11, ... DBX0.0
MDA DB11, ... DBX0.1
JOG DB11, ... DBX0.2
REPOS DB11, ... DBX1.1
REF DB11, ... DBX1.2
TEACH IN DB11, ... DBX1.0
INC 1 ... 10 000, INC Var. (starting from SW
5)
DB11, ... DBB2, Bit 0 to 5
Source:
MCP key
Destination:
Interface DB (parameter ChanNo)
INC 1 ... 10 000, INC Var. (till SW 4) DB21, ... DBB13, Bit 0 to 5
INC 1 ... 10 000, INC Var. (till SW 4) DB21, ... DBB17, Bit 0 to 5
INC 1 ... 10 000, INC Var. (till SW 4) DB21, ... DBB21, Bit 0 to 5
Source:
MCP key
Destination:
Interface DB (all axis DBs)
INC 1 ... 10 000, INC Var. (till SW 4) DB31, ... DBB5, Bit 0 to 5
