Detailed description
2.13 Signal/data descriptions
Basic logic functions: PLC Basic program powerline (P3 pl)
270 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
User areas in DB2
Area Address Message number
Axis/spindle 1 DBX144.0 - DBX145.7 600.100 - 600.115
Axis/spindle 2 DBX146.0 - DBX147.7 600.200 - 600.215
Axis/spindle 3 DBX148.0 - DBX149.7 600.300 - 600.315
Axis/spindle 4 DBX150.0 - DBX151.7 600.400 - 600.415
Axis/spindle 5 DBX152.0 - DBX153.7 600.500 - 600.515
Axis/spindle 6 DBX154.0 - DBX155.7 600.600 - 600.615
Axis/spindle 7 DBX156.0 - DBX157.7 600.700 - 600.715
Axis/spindle 8 DBX158.0 - DBX159.7 600.800 - 600.815
Axis/spindle 9 DBX160.0 - DBX161.7 600.900 - 600.915
Axis/spindle 10 DBX162.0 - DBX163.7 601.000 - 601.015
Axis/spindle 11 DBX164.0 - DBX165.7 601.100 - 601.115
Axis/spindle 12 DBX166.0 - DBX167.7 601.200 - 601.215
Axis/spindle 13 DBX168.0 - DBX169.7 601.300 - 601.315
Axis/spindle 14 DBX170.0 - DBX171.7 601.400 - 601.415
Axis/spindle 15 DBX172.0 - DBX173.7 601.500 - 601.515
Axis/spindle 16 DBX174.0-DBX175.7 601.600 - 601.615
Axis/spindle 17 DBX176.0 - DBX177.7 601.700 - 601.715
Axis/spindle 18 DBX178.0 - DBX179.7 601.800 - 601.815
Axes 19 to 31 are not currently
implemented
