Detailed description
2.12 Block descriptions
Basic logic functions: PLC basic program solution line (P3 sl)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
131
PI service: SETUDT
Set function current user data active
The current user data, such as tool offsets, basic frames and settable frames are set to
active in the next NC block (only in STOP state).
Parameterization
Signal Type Value range Meaning
PIService ANY PI.SETUDT Activate user data
Unit INT 1 to 10 Channel
WVar1 WORD 1 to 5 User data type
1 = active tool offset
2 = active basic frame
3 = active settable frame
4 = active global basic frame
5 = active global settable frame
WVar2 WORD 0 Standby
WVar3 WORD 0 Standby
PI service: SETUFR
Activate function user frames:
User frames are loaded to the NCK. All necessary frame values must be transferred to the
NCK beforehand by writing variables with FB 3.
Parameterization
Signal Type Value range Meaning
PIService ANY PI.SETUFR Activate
user frames
Unit INT 1 to 10 Channel
