4.2 Protection zones
Basic logic functions: Axis monitoring, protection zones (A3)
76 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
$SN_PA_CENT_ORD[1.6] 0 ; Midpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 6
$SN_PA_CENT_ORD[1.7] 0 ; Midpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 7
$SN_PA_CENT_ORD[1.8] 0 ; Midpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 8
$SN_PA_CENT_ORD[1.9] 0 ; Midpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 9
$SN_PA_CENT_ABS[0,0] 0 ; Midpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 0
$SN_PA_CENT_ABS[0.1] -30 ; Midpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 1
$SN_PA_CENT_ABS[0,2] 0 ; Midpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 2
$SN_PA_CENT_ABS[0,3] 0 ; Midpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 3
$SN_PA_CENT_ABS[0,4] 0 ; Midpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 4
$SN_PA_CENT_ABS[0,5] 0 ; Midpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 5
$SN_PA_CENT_ABS[0,6] 0 ; Midpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 6
$SN_PA_CENT_ABS[0,7] 0 ; Midpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 7
$SN_PA_CENT_ABS[0,8] 0 ; Midpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 8
$SN_PA_CENT_ABS[0,9] 0 ; Midpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 9
$SN_PA_CENT_ABS[1.0] 0 ; Midpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 0
$SN_PA_CENT_ABS[1.1] -30 ; Midpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 1
$SN_PA_CENT_ABS[1.2] 0 ; Midpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 2
$SN_PA_CENT_ABS[1.3] 0 ; Midpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 3
$SN_PA_CENT_ABS[1.4] 0 ; Midpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 4
$SN_PA_CENT_ABS[1.5] 0 ; Midpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 5
$SN_PA_CENT_ABS[1.6] 0 ; Midpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 6
$SN_PA_CENT_ABS[1.7] 0 ; Midpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 7
$SN_PA_CENT_ABS[1.8] 0 ; Midpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 8
$SN_PA_CENT_ABS[1.9] 0 ; Midpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 9
