Ranges of values
Ranges of values of data types
Data type Representable numerical range
BOOL 0, 1
BYTE 0 ... 255
WORD 0 ... 65535
INT - 32768 to + 32767
DWORD 0 ... 9999999
DINT - 9999999 to + 9999999
REAL (Digits := 1) - 999999.9 to + 999999.9
REAL (Digits := 2) - 99999.99 to + 99999.99
REAL (Digits := 3) - 9999.999 to + 9999.999
REAL (Digits := 4) - 999.9999 to + 999.9999
Call example
CALL FC 13 (
Row := MB 26,
ChrArray := "strdat".disp, //DB with name strdat in the symbol table,
//Data element disp is declared as String[32]
//and completely assigned with sign
Convert := M 90.1,
Addr := P#M 20.0, //Number to be converted
DataType := MB 28, //Data type of the variables
StringAddr := MW 30,
Digits := B#16#3, //3 decimal places
Error := M 90.2);
