Detailed description
2.12 Block descriptions
Basic logic functions: PLC basic program solution line (P3 sl)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
221
Description of formal parameters
The table below shows all formal parameters of the "MCP_IFM" function:
Signal Type Type Range of values Remark
BAGNo I BYTE 0 - b#16#0A and
b#16#10 -
b#16#1A
No. of mode group to which the mode signals are
transferred.
BAGNo >= b#16#10 means access to the
second machine control panel.
ChanNo I BYTE 0 - B#16#0A Channel no. for the channel signals
SpindleIFNo I BYTE 0 - 31
(B#16#1F)
Number of the axis interface declared as a spindle
FeedHold A BOOL Feed stop from MCP, modal
SpindleHold A BOOL Spindle stop from MCP, modal
MCP selection signals to the user interface
Key-operated switch
Source:
MCP - Switch
Destination:
Interface DB
Position 0 DB10, ... DBX56.4
Position 1 DB10, ... DBX56.5
Position 2 DB10, ... DBX56.6
Position 3 DB10, ... DBX56.7
Operating modes and machine functions
Source:
MCP - Key
Destination:
Interface DB (parameter BAGNo)
AUTOMATIC DB11, ... DBX0.0
MDI DB11, ... DBX0.1
JOG DB11, ... DBX0.2
REPOS DB11, ... DBX1.1
REF DB11, ... DBX1.2
TEACH IN DB11, ... DBX1.0
INC 1 ... 10 000, INC Var. DB11, ... DBB2, Bit 0 to 5
