Detailed description
2.2 Exact stop
Basic logic functions: Continuouspath Mode, Exact Stop, LookAhead (B1)
14 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Ones position = 2:
With rapid traverse, exact stop criterion G602 (exact stop window coarse) is always active,
irrespective of any programming in the part program.
Tens digit = 0:
For traversing with all other part program commands of the first G-group, the exact stop
criterion programmed in the part program is active.
Assignable exact stop criterion for rapid traverse transitions in continuous path mode
The behavior at the block transition of part program blocks before and after rapid traverse
blocks can be parameterized via the following channel-specific machine data:
MD20552 $MC_EXACT_POS_MODE_G0_TO_G1 = <
value
> (exact stop condition for G00-
G01 transition)
Value Meaning
0 no additional stop at block transition
1 Stop at block transition: Behavior according to G601 (Exact stop window fine)
2 Stop at block transition: Same behavior as in the case of G602 (exact stop window coarse)
3 Stop at block transition: Same behavior as G603 (interpolator end)
4 Like 0; in addition, the override of the next non-G00 block is taken into account with
LookAhead in the G00 block during the transition from G00 to non-G00.
5 Like 0; in addition, the override of the next block is taken into account with LookAhead
during the transition from G00 to non-G00 and non-G00 to G00.
