Detailed Description
2.4 Selectable spindles
Basic logic functions: Spindles (S1)
66 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Basic position SD42800
After switching on the NC in installation switch position 1 (Delete SRAM)
the setting data:
SD42800 $SC_SPIND_ASSIGN_TAB[...]
is in the basic position.
The numbers of the logical and physical spindles are identical.
SD42800 $SC_SPIND_ASSIGN_TAB[1] = 1
SD42800 $SC_SPIND_ASSIGN_TAB[2] = 2
SD42800 $SC_SPIND_ASSIGN_TAB[3] = 3
SD42800 $SC_SPIND_ASSIGN_TAB[4] = 4
SD42800 $SC_SPIND_ASSIGN_TAB[5] = 5
...
Example
Assumptions: Spindle configurations:
Specifying the spindle number and machine axis
MD35000 $MA_SPIND_ASSIGN_TO_MACHAX [AX4] = 1
MD35000 $MA_SPIND_ASSIGN_TO_MACHAX [AX5] = 2
MD35000 $MA_SPIND_ASSIGN_TO_MACHAX [AX6] = 3
MD35000 $MA_SPIND_ASSIGN_TO_MACHAX [AX7] = 5
Applying a machine axis in the channel
MD20070 $MC_AXCONF_MACHAX_USED[0] = 4
MD20070 $MC_AXCONF_MACHAX_USED[1] = 5
MD20070 $MC_AXCONF_MACHAX_USED[2] = 6
MD20070 $MC_AXCONF_MACHAX_USED[3] = 7
Specifying the master spindle
MD20090 $MC_SPIND_DEF_MASTER_SPIND = 1
Spindle number converter
MD20092 $MC_SPIND_ASSIGN_TAB_ENABLE = 1
Activate spindle number converter
SD42800 $SC_SPIND_ASSIGN_TAB[0] = 1
Master spindle as configured
SD42800 $SC_SPIND_ASSIGN_TAB[1] = 1
Basic table setting
SD42800 $SC_SPIND_ASSIGN_TAB[2] = 2
SD42800 $SC_SPIND_ASSIGN_TAB[3] = 3
SD42800 $SC_SPIND_ASSIGN_TAB[4] = 0
Logical spindle not assigned
M3 S1000
Address extension = 1, M1=3 S1=1000 is output. The spindle with the configured No.
"1" (No. of physical master spindle) rotates.
...
...
