Detailed Description
2.1 Various interface signals and functions (A2)
Basic logic functions: NC/PLC interface signals (Z1)
38 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
DB31, ...
DBX20.0
Rampup times
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
V/f operation operation is activated using machine data:
MD1014 $MD_U/F_MODE_ENABLE.
The time entered in the machine data:
MD1126 $MD_U/F_MODE_RAMP_TIME_2
is effective.
Signal state 0 or
edge change
1 → 0
V/f operation operation is activated using machine data:
MD1014 $MD_U/F_MODE_ENABLE.
The time entered in the machine data:
MD1125 $MD_U/F_MODE_RAMP_TIME_1
is effective.
Signal irrelevant for
...
SINUMERIK 840Di
Corresponding to .... MD1014 $MD_U/F_MODE_ENABLE (activate V/f operation)
MD1125 $MD_UF_MODE_RAMP_TIME_1 (ramp-up time 1 for V/f mode)
MD1126 $MD_UF_MODE_RAMP_TIME_2 (ramp-up time 2 for V/f mode)
Additional references /FBA/ SIMODRIVE 611D Functions Manual Drive Functions
DB31, ...
DBX20.1 Rampfunction generator fast stop
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
A fast stop is triggered by the PLC for the drive (611D). Speed setpoint 0 is therefore entered. The
drive is stopped without a ramp function (regenerative braking).
As soon as the fast stop is recognized by the drive module, the interface signal:
DB31, ... DBX92.1 (Ramp-function generator fast stop active) is returned to the PLC.
Signal state 0 or
edge change
1 → 0
No rapid stop is requested by the PLC for the drive.
Signal irrelevant for
...
SINUMERIK 840Di
Corresponding to .... DB31, ... DBX92.1 (ramp-function generator fast stop active)
Additional references /IAD/ SINUMERIK 840D Startup Guide; Chapter: SIMODRIVE 611D
