Detailed Description
2.1 Various interface signals and functions (A2)
Basic logic functions: NC/PLC interface signals (Z1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
49
DB31, ...
DBX93.0 - DBX93.2 Active drive parameter set A, B, C
Edge evaluation: no Signal(s) updated: cyclic
Meaning The drive module (611D/611U) signals back to the PLC which drive parameter set is currently
active.
With bit combinations A, B and C, 8 different drive parameter sets can be selected for the 611D.
The following assignment applies:
DFWLYHGULYHSDUDPHWHUVHW








&








%








$








Application
example(s)
Drive parameter switchover can be used for the following:
• To change the gear stage
• To change over the measuring circuit
Corresponding to .... DB31, ... DBX21.0 - DBX21.2 (drive parameter set selection)
Additional references DB31, ... DBX21.0 - DBX21.2 (drive parameter set selection)
or
/IAD/ SINUMERIK 840D Installation and Start-up Guide; Chapter: SIMODRIVE 611D
or
/IAC/ SINUMERIK 810D Installation and Start-up Guide
