Detailed Description
2.9 Mode group, channel, program operation, reset response (K1)
Basic logic functions: NC/PLC interface signals (Z1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
105
DB21, ...
DBX319.5
Repos DEFERAL Chan
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
All axes currently controlled by this channel have either no REPOS offset or their REPOS offsets
are invalid.
Signal state 0 or
edge change
1 → 0
Miscellaneous.
Corresponds to .... DB31, ... DBX70.0 (Repos offset)
DB21, ...
DBB376
PROG-EVENT-DISPLAY
Edge evaluation: no Signal(s) updated: event-driven
Signal state 1 or
edge change
0 → 1
The event associated with the bit has occurred.
Signal state 0 or
edge change
1 → 0
The event associated with the bit is no longer pending.
Bit assignments Bit 0 → part program start from channel status RESET
Bit 1 → end of part program
Bit 2 → operator panel reset
Bit 3 → run-up
Bit 4 → 1st start after the search run
Bit 5 - 7 → reserved, currently always 0 part program
All bits 0 → no PROG-EVENT is active
Signal duration: at least one complete PLC cycle
