Detailed Description
2.15 Spindles (S1)
Basic logic functions: NC/PLC interface signals (Z1)
116 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
DB31, ...
DBX16.0 - DBX16.2
Actual gear stage A to C
Edge evaluation: yes Signal(s) updated: cyclic
Signal state 1
(statuscontrolled)
If the new gear stage is engaged, the PLC user program sets the interface signals:
DB31, ... DBX16.2 - DBX16.0 (actual gear stage A to C)
and
DB31, ... DBX16.3 (gear is changed over).
This signals the NCK that the correct gear stage has been successfully engaged.
The gear change is considered to have been completed (spindle oscillation mode is deselected),
the spindle accelerates in the new gear stage to the last programmed spindle speed and the next
block in the parts program can be executed.
The actual gear stage is output in coded format.
For each of the 5 gear stages, there is one set of parameters assigned as follows:
3DUDPHWHUVHW1R 1&3/&LQWHUIDFH 0HDQLQJ
'DWDIRUD[LVPRGH
'DWDIRUVWJHDUVWDJH
'DWDIRUQGJHDUVWDJH
'DWDIRUUGJHDUVWDJH
'DWDIRUWKJHDUVWDJH
'DWDIRUWKJHDUVWDJH
ದ
Special cases,
errors, ......
If the PLC user program signals a different actual gear stage back to the NCK than that issued by
the NCK as the setpoint gear stage, the gear stage change is still considered as having been
successfully completed and the actual gear stage A to C is activated.
Corresponding to .... DB31, ... DBX82.0 - DBX82.2 (setpoint gear stage A to C)
DB31, ... DBX82.3 (change over gear stage)
DB31, ... DBX16.3 (gear stage is changed over)
DB31, ... DBX18.5 (oscillation speed)
Parameter sets for gear stages
