Siemens SINUMERIK 810D

Detailed description
2.1 Velocities, traversing ranges, accuracies
Basic logic functions: Velocities, Setpoint/Actual Value Systems, Closed-Loop Control (G2)
16 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
For this, the machine data:
MD10220 $MN_SCALING_USER_DEF_MASK
(activation of scaling factors)
and
MD10230 $MN_SCALING_FACTORS_USER_DEF[n]
(Scaling factors of physical quantities)
allow you to set the adaptation between the newly selected input/output units and the
internal units.
,QSXWRXWSXWXQLWVIRUPDFKLQH
DQGVHWWLQJGDWD
&RQYHUVLRQRILQWHUQDOXQLWV
,QWHUQDOXQLWV
8VHUGHILQHG
0'6&$/,1*B)$&7256B86(5B'()>Q@
0'6&$/,1*B)$&7256B86(5B'()B0$6.
'RWKH
LQSXWRXWSXWXQLWVFRUUHV
SRQGWRWKHVWDQGDUGEDVLF
V\VWHP"
LQFKRUPHWULF
1R
<HV
The following applies:
Selected input/output unit = MD10230 * internal unit
In the machine data:
MD10230 $MN_SCALING_FACTORS_USER_DEF[n]
the selected input/output unit printed in each case in the internal units 1mm, 1 degree and 1
s must be input.
