Brief description
1.2 Overview of auxiliary functions
Basic logic functions: Auxiliary Function Output to PLC (H2)
12 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
F functions
F (feedrate)
Address extension Value
Value range Meaning Value range Type Meaning Number
8)
- - - - - - 0.001 - 999 999.999 REAL Path feed 6
Remarks:
- - -
Application
Path velocity.
Remarks
• F-function-specific machine data:
MD22240 $MC_AUXFU_F_SYNC_TYPE (output time of F functions)
FA functions
FA (axial feedrate)
Address extension Value
Value range Meaning Value range Type Meaning Number
8)
1 - 31 Axis number 0.001 - 999 999.999 REAL Axial feedrate 6
Remarks:
- - -
Application
Axial velocity.
Remarks
• F-function-specific machine data:
MD22240 $MC_AUXFU_F_SYNC_TYPE (output time of F functions)
