Siemens SINUMERIK 810D Function Manual

Examples
4.1 Defining auxiliary functions
Basic logic functions: Auxiliary Function Output to PLC (H2)
62 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Programming Remarks
$MC_AUXFU_ASSIGN_VALUE[13] = 4
$MC_AUXFU_ASSIGN_GROUP[13] = 10
$MC_AUXFU_ASSIGN_TYPE[14] = "M"
Description of auxiliary function 15: M2 = 5
$MC_AUXFU_ASSIGN_EXTENSION[14] = 2
$MC_AUXFU_ASSIGN_VALUE[14] = 5
$MC_AUXFU_ASSIGN_GROUP[14] = 10
$MC_AUXFU_ASSIGN_TYPE[15] = "M"
Description of auxiliary function 16: M2 = 70
$MC_AUXFU_ASSIGN_EXTENSION[15] = 2
$MC_AUXFU_ASSIGN_VALUE[15] = 70
$MC_AUXFU_ASSIGN_GROUP[15] = 10
$MN_AUXFU_GROUP_SPEC[10] = 'H22'
Specification of auxiliary function group 11
$MC_AUXFU_ASSIGN_TYPE[16] = "S"
Description of auxiliary function 17: S2 = <all values>
$MC_AUXFU_ASSIGN_EXTENSION[16] = 2
$MC_AUXFU_ASSIGN_VALUE[16] = -1
$MC_AUXFU_ASSIGN_GROUP[16] = 11
$MN_AUXFU_GROUP_SPEC[11] = 'H21'
Specification of auxiliary function group 12
$MC_AUXFU_ASSIGN_TYPE[17] = "M"
Description of auxiliary function 18: M50
$MC_AUXFU_ASSIGN_EXTENSION[17] = 0
$MC_AUXFU_ASSIGN_VALUE[17] = 50
$MC_AUXFU_ASSIGN_GROUP[17] = 12
$MC_AUXFU_ASSIGN_TYPE[18] = "M"
Description of auxiliary function 19: M51
$MC_AUXFU_ASSIGN_EXTENSION[18] = 0
$MC_AUXFU_ASSIGN_VALUE[18] = 51
$MC_AUXFU_ASSIGN_GROUP[18] = 12
$MN_AUXFU_GROUP_SPEC[12] = 'H21'
Specification of auxiliary function group 13
$MC_AUXFU_ASSIGN_TYPE[19] = "M"
Description of auxiliary function 20: M52
$MC_AUXFU_ASSIGN_EXTENSION[19] = 0
$MC_AUXFU_ASSIGN_VALUE[19] = 52
$MC_AUXFU_ASSIGN_GROUP[19] = 13
$MC_AUXFU_ASSIGN_TYPE[20] = "M"
Description of auxiliary function 21: M53
$MC_AUXFU_ASSIGN_EXTENSION[20] = 0
$MC_AUXFU_ASSIGN_VALUE[20] = 53
$MC_AUXFU_ASSIGN_GROUP[20] = 13
