Detailed description
2.10 System settings for power-up, RESET/part-program end and part-program start
Basic logic functions: Mode group, channel, program operation, reset response (K1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
169
Table 2-16 Effect of MD20110 $MC_RESET_MODE_MASK Bits 13 to 17 (in SW 6.4 and higher, Bit 16 to Bit 17)
Bit 13 = 1 Bit 14 = 1 Bit 15 = 1 Bit 16 = 1 Bit 17 = 1
Active guide value
coupling is
retained
The current setting
of the basic frame
is retained.
The active
electronic gears
are deactivated
The current setting
of the master
spindle is retained.
The current setting
of the master tool
holder is retained.
Bit 13 = 0 Bit 14 = 0 Bit 15 = 0 Bit 16 = 0 Bit 17 = 0
Guide value
coupling is
separated
Basic frame is
deselected
The active
electronic gears
are retained
Initial setting for
the master spindle
according to
MD20090
Initial setting for
the master tool
holder according
to MD20124
RESET response of master spindle
Up to SW 6.3 the master spindle setting was reset to the configured value on M30/RESET.
Depending on the setting of Bit 0 of MD20110 $MC_RESET_MODE_MASK, there are two
cases:
Bit 0 = 0:
No Init blocks are generated. (Default: the current settings are retained)
Bit 0 = 1:
Init blocks are generated. The settings activated by RESET become valid.
