Detailed description
2.11 Subroutine call through NC language replacement
Basic logic functions: Mode group, channel, program operation, reset response (K1)
184 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Example of tool change with M6 is active and MD10719 $MN_ T_NO_FCT_CYCLE_MODE= 0
MD10719 $MN_T_NO_FCT_CYCLE_MODE = 0 (parameterization of T function
replacement)
MD10717 $MN_T_NO_FCT_CYCLE_NAME = "MY_T_CYCLE" (name of tool change for T
function replacement); T replacement cycle
N210 D1
;
N220 G90 G0 X100 Y100 Z50
; D1 is active
N230 D2 X110 Z0 T5
; D1 remains active, programmed D2 is provided
to the T replacement cycle as a variable
N240 M6
; New tool is selected
Expanded behavior:
Tool change with M6 is active and MD10719 $MN_T_NO_FCT_CYCLE_MODE= 1
MD22550 $MC_TOOL_CHANGE_MODE = 1 ;(Tool change with M function)
MD10719 $MN_T_NO_FCT_CYCLE_MODE = 1
MD10717 $MN_T_NO_FCT_CYCLE_NAME = "MY_T_CYCLE" ;T replacement cycle
N310 D1
;
N320 G90 G0 X100 Y100 Z50
; D1 is active
N330 D2 X110 Z0 T5
; D2 is activated, D2 is not transferred to
the T replacement cycle as a variable
N340 M6
; T5 is activated
Example also with parameter transfer on tool change with M6 active and MD10719 = 1
• A replacement cycle for T and M6 has been configured.
• In addition, MD10718 $MN_M_NO_FCT_CYCLE_PAR (M Function replacement with
parameters) was used to configure the parameter transfer to M6 replacement cycle.
If M6 is now programmed with D- or DL in the block, then D or DL No. is also passed as
parameter to the M6 replacement system, if it is
MD10719 $MN_T_NO_FCT_CYCLE_MODE = 1 (parameterization of the T function
replacement).
MD22550 $MC_TOOL_CHANGE_MODE = 1 ;(Tool change with M functions)
MD10719 $MN_T_NO_FCT_CYCLE_MODE = 1
MD10717 $MN_T_NO_FCT_CYCLE_NAME = "MY_T_CYCLE" ;(name of tool change for T
function replacements); T replacement cycle
N410 D1
;
N420 G90 G0 X100 Y100 Z50
; D1 is active
N430 D2 X110 T5 M6
; D1 remains active, D2 and T5 are transferred
to the M6 replacement cycle as a variable
