12.3 SIRIUS infeed system for 3RA6
SIRIUS 3RA6 Compact Starter
112 System Manual, 02/2008, GWA 4NEB 560 0601-02 DS 02
12.3.8 Connecting the SIRIUS infeed system for 3RA6
The SIRIUS infeed system for 3RA6 is available with screw-type and spring-loaded
connection technology.
The main conductors (L1, L2, L3) can be connected to the screw-type infeed (25/35 mm
2
)
and screw-type infeed (50/70 mm
2
) from both the top and the bottom.
Stripping lengths
The following stripping lengths apply to the SIRIUS infeed system for 3RA6:
Table 12-4 Stripping lengths (infeed system for 3RA6)
Connecting terminal Order number Stripping length
Screw-type infeed (25/35 mm
2
) 3RA6812-8AB
3RA6812-8AC
Line side: 13 mm and
outgoing side: 10 mm
Screw-type infeed (50/70 mm
2
) 3RA6813-8AB
3RA6813-8AC
Line side: 17 mm and
outgoing side: 10 mm
Extension modules with screw-type and
spring-loaded connection technology
3RA6822-0AB
3RA6822-0AC
3RA6823-0AB
3RA6823-0AC
10 mm
Spring-loaded infeed 3RA6830-5AC 23 mm
PE infeed, 25/35 mm
2
,
screw-type connection technology
3RA6860-6AB 13 mm
PE infeed, 25/35 mm
2
,
spring-loaded connection technology
3RA6860-5AC 23 mm
PE tap 3RA6870-4AB
3RA6870-3AC
10 mm
Terminal block 3RV1917-5D 12 mm
