Dimension drawings
15.1 SIRIUS 3RA6 compact starter
SIRIUS 3RA6 Compact Starter
162 System Manual, 02/2008, GWA 4NEB 560 0601-02 DS 02
3RA6 compact starter (spring-loaded connection technology)
5
Figure 15-2 Side view of the 3RA6 compact starter (spring-loaded connection technology)
(1) Push-in lug for screw fastening
(2) Adapter for screw fastening
