Dimension drawings
15.2 SIRIUS infeed system for 3RA6
SIRIUS 3RA6 Compact Starter
168 System Manual, 02/2008, GWA 4NEB 560 0601-02 DS 02
15.2.2 Minimum distances from neighboring components (dimensions in mm)
Distance from neighboring components
When installing the infeed system for 3RA6, the following distances from neighboring parts
must be observed.
!
!
!
!
Figure 15-10 Distances from neighboring components (infeed system for 3RA6)
Note
The lateral distances are minimum distances from grounded components.
The distances at the top and bottom are required in order to provide an arcing space!
