Diagnostics
11.2 AS-i mounting module diagnostics
SIRIUS 3RA6 Compact Starter
System Manual, 02/2008, GWA 4NEB 560 0601-02 DS 02
87
11.2 AS-i mounting module diagnostics
The status of the AS-i mounting module is indicated by means of two LEDs, which will either
light up continuously or flash. Making straightforward diagnostics available directly on the
AS-i mounting module in this way enables the user to troubleshoot quickly and efficiently.
Display concept on the AS-i mounting module
Table 11-3 Display concept of the "AS-i/FAULT" LED
AS-i/FAULT LED
Green OFF Red Red/yellow
Operating status Communication
OK
No voltage on
AS-Interface chip
Communication
failure
Slave has the
address "0"
Table 11-4 Display concept of the "AUX PWR" LED
AUX PWR LED
Green OFF
AUX PWR Voltage present No voltage
