Siemens SIRIUS Series System Manual

Appendix
A.2 List of abbreviations
SIRIUS 3RA6 Compact Starter
174 System Manual, 02/2008, GWA 4NEB 560 0601-02 DS 02
A.2 List of abbreviations
Abbreviation/Symbol Term
Conductor, solid and stranded
Conductor, finely stranded without end sleeve
Conductor, finely stranded with end sleeve
LED not illuminated
LED illuminated green
No mechanical display
Mechanical display is white
Screw-type infeed (50/70 mm
2
) Left infeed, 50/70 mm² screw terminal with three slots, outgoing
terminals with screw-type or spring-loaded connection
technology, incl. PE bar
Screw-type infeed (25/35 mm
2
) Left infeed, 25/35 mm² screw terminal with three slots, outgoing
terminals with screw-type or spring-loaded connection
technology, incl. PE bar
Spring-loaded infeed Left or right infeed, 25/35 mm², with spring-loaded connection
technology
2-slot extension module Extension module with two slots, outgoing terminals with
screw-type or spring-loaded connection technology, incl. PE bar
3-slot extension module Extension module with three slots, outgoing terminals with
screw-type or spring-loaded connection technology, incl. PE bar
PZ Pozidriv
SW Width across flats
