Siemens SIRIUS Series System Manual

Dimension drawings
15.1 SIRIUS 3RA6 compact starter
SIRIUS 3RA6 Compact Starter
System Manual, 02/2008, GWA 4NEB 560 0601-02 DS 02
163
15.1.2 Minimum distances from neighboring components (dimensions in mm)
Distance from neighboring components
When installing compact starters, the following distances from grounded or live parts and
from neighboring components must be observed in accordance with IEC / EN 60947-6-2.
!
!
!
!
Note
The lateral distances are minimum distances from grounded components.
The distances at the top and bottom are required in order to provide an arcing space!
