13.5 Order numbers
SIRIUS 3RA6 Compact Starter
System Manual, 02/2008, GWA 4NEB 560 0601-02 DS 02
141
Example
Options
SIRIUS 3RA6 compact starter
3RA6 ① 0 - ② ③ ④ ⑤
Compact starter:
Direct starter version ① ➜ 12
Terminal connection type
All terminals with screw-type connection technology ② ➜ 1
Current setting range
1 to 4 A ③ ➜ C
Control voltage range (AC/DC)
24 V ④ ➜ B3
Terminal configuration
With main conductor terminals and control conductor terminals
for attachment to a DIN rail
⑤ ➜ 2
Order number: ➜ 3RA6 12 0 - 1 C B3 2
13.5.2 Order numbers for accessories
SIRIUS 3RA6 compact starter
System component Order number
Main conductor terminal
(2 units per pack)
- Screw-type connection technology
- Spring-loaded connection technology
3RA6920-1A
3RA6920-2A
Terminal for self-protected combination motor controller (Type E) to UL 508 3RV1928-1H
Auxiliary switch block for compact starter
- Screw-type connection technology:
2 NO contacts
2 NC contacts
1 NO contact + 1 NC contact
- Spring-loaded connection technology:
2 NO contacts
2 NC contacts
1 NO contact + 1 NC contact
3RA6911-1A
3RA6912-1A
3RA6913-1A
3RA6911-2A
3RA6912-2A
3RA6913-2A
AS-i mounting module for compact starter 3RA6970-3A
AS-i mounting module for compact starter with two local inputs for safe
shutdown
3RA6970-3B
Addressing unit 3RK1904-2AB01
Control kit 3RA6950-0A
Adapter for screw fastening the compact starter 3RA6940-0A
