Accessories
12.3 SIRIUS infeed system for 3RA6
SIRIUS 3RA6 Compact Starter
96 System Manual, 02/2008, GWA 4NEB 560 0601-02 DS 02
Figure 12-1 Infeed system for 3RA6
(1) Screw-type infeed (25/35 mm
2
)
(2) Screw-type infeed (50/70 mm
2
)
(3) Spring-loaded infeed
(4) Extension block
