Configuration
4.2 Supply possibilities in main circuit
SIRIUS 3RA6 Compact Starter
34 System Manual, 02/2008, GWA 4NEB 560 0601-02 DS 02
4.2.2 3-phase busbar
Rated current/operating voltage
● Rated operating voltage: 690 V
● Rated current: 63 A
Combination with other sizes
The compact starters can be combined with size S0 circuit breakers using the
3-phase busbar (3RV1915-1.B) as well as with size S00 circuit breakers using the
connection piece (3RV1915-5DB).
59 $%
59 %
59 '%
Figure 4-5 Combination with other sizes (3-phase busbar)
