Siemens SIRIUS Series

Technical data
14.3 SIRIUS infeed system for 3RA6
SIRIUS 3RA6 Compact Starter
System Manual, 02/2008, GWA 4NEB 560 0601-02 DS 02
159
Conductor cross-sections of PE tap, 6/10 mm
2
, with spring-loaded connection technology
Order number 3RA6870-3AC
Type of connection Spring-loaded connection
Tool 8WA2 803
(3.5 x 0.5) mm
Conductor cross-sections
Solid
Finely stranded without end sleeve
Finely stranded with end sleeve
AWG cables
mm
2
mm
2
mm
2
AWG
AWG
1,5 ... 10
1,5 ... 6
1,5 ... 6
16 to 10
1 x 8
Terminal block
Order number 3RV1917-5D
Type of connection Spring-loaded connection
Tool 8WA2 803
8WA2 804
(3.5 x 0.5) mm
Conductor cross-sections
Solid
Finely stranded without end sleeve
Finely stranded with end sleeve
AWG cables
mm
2
mm
2
mm
2
AWG
1,5 ... 6
1,5 ... 6
1,5 ... 4
15 to 10
