Technical data
14.2 AS-i mounting module
SIRIUS 3RA6 Compact Starter
System Manual, 02/2008, GWA 4NEB 560 0601-02 DS 02
155
14.2 AS-i mounting module
General technical data
Order number 3RA6970-3A
3RA6970-3B
Permissible ambient temperature
Storage/shipping
According to IEC / EN 60721-3-1
(storage), IEC / EN 60721-3-2
(shipping)
°C
-25 to +70
Degree of protection According to IEC / EN 60947-1 IP20
EMC interference immunity
Conducted interference
Electrostatic discharge
According to EN 50295
BURST according to IEC /
EN 61000-4-4
According to IEC / EN 61000-4-2
kV
kV
½
6/8
Field-based interference suppression According to IEC / EN 61000-4-3 V/m 10 (80 MHz ... 2.7 GHz)
Conductor cross-sections of AS-i mounting module 3RA6970-3B
Order number 3RA6970-3B
Type of connection Screw connection
Tool Pozidriv, size 1
Specified tightening torque Nm 0.5 ... 0.6 Nm
Conductor cross-sections
Solid
Finely stranded with end
sleeve
AWG cables
mm
2
mm
2
mm
2
mm
2
AWG
1 x (0.5 ... 2.5)
2 x (0.5 ... 1.0)
1 x (0.5 ... 2.5)
2 x (0.5 ... 1.0)
1 x (20 to 12)
