Technical data
14.3 SIRIUS infeed system for 3RA6
SIRIUS 3RA6 Compact Starter
156 System Manual, 02/2008, GWA 4NEB 560 0601-02 DS 02
14.3 SIRIUS infeed system for 3RA6
General data
Order number 3RA68.
Frequency 50/60 Hz
Permissible ambient temperature
Storage / transport
operation
Permissible rated current of compact starter at
the following internal control cabinet
temperatures:
+ 40 °C
+ 60 °C
°C
°C
%
%
-55 ... +80
-20 ... +60
1)
100
80
Max. rated current I
r max
Left infeed, 50/70 mm² screw terminal with
three slots, outgoing terminals with screw-type
and spring-loaded connection technology, incl.
PE bar
Left infeed, 25/35 mm² screw terminal with
three slots, outgoing terminals with screw-type
and spring-loaded connection technology, incl.
PE bar
Left or right infeed, 25/35 mm², with spring-
loaded connection technology
Extension connector
Order number
3RA6813-8AB
3RA6813-8AC
3RA6812-8AB
3RA6812-8AC
3RA6830-5AC
3RA6890-1AB
A
A
A
A
100
63
63
63
Installation altitude m 2000 m above sea level
without any restrictions
Vibratory load
Shock
f = 1 to 6 Hz; d = 15 mm
10 cycles
f = 150 Hz; a = 2g
a = 60 m/s
2
(6g) with 10 ms
every 3
All axes subjected to shock
Degree of protection
Touch protection
According to IEC / EN 60947-1
According to DIN EN 50274
IP20 (connection compartment
IP 00)
Finger-safe
Rated operating voltage U
e
V 690 AC
Degree of pollution 3
Short-circuit protection for spring-loaded infeed
4 mm²
6 mm²
10 mm²
16 mm²/25 mm²
I
d,max
< 9.5 kA, I²t = 85 kA²s
I
d,max
< 12.5 kA, I²t = 140 kA²s
I
d,max
< 15 kA, I²t = 180 kA²s
I
d,max
< 19 kA, I²t = 440 kA²s
3RV1021-4DA10
2)
3RV1031-4EA10
2)
3RV1031-4HA10
2)
3RV1041-4JA10
2)
