Accessories
12.6 Terminal for Type E combination motor controller, UL 508
SIRIUS 3RA6 Compact Starter
128 System Manual, 02/2008, GWA 4NEB 560 0601-02 DS 02
12.6.2 Connecting the terminal for a Type E self-protected combination motor controller
(UL 508)
Conductor cross-sections
Table 12-13 Conductor cross-sections of the terminal for a self-protected combination motor
controller (Type E) to UL 508
3RV1928-1H
∅ 5 ... 6 mm/PZ 2
2.5 … 3 Nm
(22 to 26.5 lb·in)
(1 … 10) mm
2
(1 … 10) mm
2
Max. 10 + max. 10 mm
2
(2.5 … 25) mm
2
(1.5 … 25) mm
2
Max. 10 + max. 25 mm
2
(1 … 16) mm
2
(1 … 16) mm
2
Max. 10 + max. 10 mm
2
Max. 6 + max. 16 mm
2
AWG 14 to 3 16 to 3 Max. 6 + max. 3
